Specifications

application / industry

Heavy Machinery

direction of winding

—

end type

—

free length (mm)

—

heat treatment

Hardened

inner diameter id (mm)

—

load at specified length (n)

—

load type

Compression

material

Spring Steel

mounting style

Seated

number of active coils

—

operating temperature (°c)

-40 to 200

outer diameter od (mm)

20, 25, 32, 40, 50, 63, 80

solid length (mm)

—

spring function

Load Bearing

spring rate (n/mm)

—

spring shape

Volute

standard / specification

OEM

surface finish / coating

Plain

wire diameter (mm)

—
