Specifications

application / industry

Conveyors

direction of winding

—

end type

Hook

free length (mm)

405075100150

heat treatment

Stress Relieved

inner diameter id (mm)

—

load at specified length (n)

—

load type

Extension

material

Carbon Steel

mounting style

Hooked

number of active coils

—

operating temperature (°c)

-40 to 120

outer diameter od (mm)

10, 12, 16, 20, 25, 30, 40

solid length (mm)

—

spring function

Tension

spring rate (n/mm)

—

spring shape

Cylindrical

standard / specification

OEM

surface finish / coating

Zinc Plated

wire diameter (mm)

1, 1.2, 1.6, 2, 2.5, 3, 4, 5
