Specifications

application / industry

Clamps, Devices

direction of winding

Right Hand, Left Hand

end type

Double Leg

free length (mm)

—

heat treatment

Stress Relieved

inner diameter id (mm)

—

load at specified length (n)

—

load type

Torsion

material

Music Wire

mounting style

Dual Leg

number of active coils

—

operating temperature (°c)

-40 to 120

outer diameter od (mm)

10, 12, 16, 20, 25, 30, 40

solid length (mm)

—

spring function

Torque Storage

spring rate (n/mm)

—

spring shape

Cylindrical

standard / specification

ASTM A228

surface finish / coating

Zinc Plated

wire diameter (mm)

0.8, 1, 1.2, 1.6, 2, 2.5, 3
