Specifications

application / industry

Automation

direction of winding

—

end type

—

free length (mm)

—

heat treatment

Stress Relieved

inner diameter id (mm)

—

load at specified length (n)

—

load type

Extension

material

Stainless Steel

mounting style

Cartridge Mounted

number of active coils

—

operating temperature (°c)

-20 to 120

outer diameter od (mm)

—

solid length (mm)

—

spring function

Force Control

spring rate (n/mm)

—

spring shape

Flat Reel

standard / specification

OEM

surface finish / coating

Passivated

wire diameter (mm)

—
